The AN/APQ-174 is an American Ku band radar used on military helicopters for navigation, particularly at low level.
It was developed during the late 1980s, as a derivative of the AN/APQ-168 and LANTIRN radars. It was initially procured in the early 1990s for a variety of platforms, including U.S. Army MH-47 Chinooks and MH-60s. The radar can be used for a variety of missions, including: combat search and rescue and special forces insertion and extraction.
This podded radar has a variety of modes, including terrain-following and terrain-avoidance, ground mapping, air-to-ground ranging, weather detection/tracking, navigation, beacon interrogation, cross scan modes and power management.
Angular scan times are 5.5º/sec and the weather mode is improved during heavy rain by the use of circular polarization.
See also
- List of radars
- List of military electronics of the United States
References
- Airborne Radar Handbook ISBN 7-118-03463-0, 200 4 page 271/272, published by the National Defense Industry Publishing Co, 23 Zi Zu Yilan South Road, Hai Ding Chu, Beijing, China
- Jane's Avionics Yearbook 1991/92 page 92; Jane's Avionics Yearbook 2004/05 page 627.
